Capacity (t)

Capacity (kN)

D

D1

D2

D3

M

H

H1

H2

H3

T

T1

0.2

2

mm

75

65.5

56

-

M12×1.75

26

-

-

3

4 - Φ6.5

-

0.5 - 1

5 - 10

mm

90

78

65

22

M12×1.75

43

40

6

3

8 - Φ6.6

8 - Φ10.5

1.5 - 2.5

15 - 25

mm

105

89

75

32

M16×2

35

32

7.2

3

8 - Φ7.2

8 - Φ10.5

5 - 10

50 - 100

mm

138

110

88

44

M27×2

46

41

12

3

8 - Φ13.2

8 - Φ19

20 - 30

200 - 300

mm

165

130

96

55

M36×2

50

41

20

3

8 - Φ21

8 - Φ31

Rated output

3.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

±0.05%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input resistance

385Ω ± 5Ω

Ultimate overload

300 %F.S

Output resistance

350Ω ± 3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
