Capacity (t)

Capacity (kN)

D

D1

D2

D3

M

H

H1

H2

T1

T2

N

0.5, 1, 2, 5

5, 10, 20, 50

mm

105

89

75

32

M16 x 1.5

37

34

7.2

7.5

10.5

8

10, 15, 20

100, 150, 200

mm

120.6

101.6

83

39

M32 x 1.5

48

41

10.5

8.5

14

8

30, 50

300, 500

mm

138

116.8

96.9

50.4

M40 x 1.5

57.2

50.8

11

11

18

8

60

600

mm

153

130

110

70

M40 x 1.5

58

51

16

10.5

17

8

60, 100

600, 1000

mm

198

162

132

76

M60 x 2

83

70

18

13

20

16

150, 200

1500, 2000

mm

248

210

170

110

M80 x 3

100

90

20

17

28

16

Rated output

2.0mv/v ±0.1%

Insulation resistance

≥5000Ω

Non-linearity

±0.05%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150%F.S

Input resistance

380Ω ± 20Ω, 750Ω ± 20Ω

Ultimate overload

200%F.S

Output resistance

350Ω ± 3Ω, 700Ω ± 5Ω,

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
