Capacity (t)

Capacity (kN)

D

D1

D2

D3

M

H

H1

H2

H3

T

T1

50

500

mm

234

194

150

--

M52×2

60

55

22

4.7

16-Φ21

16-Φ32

100

1000

mm

258

218

174

--

M76×2

60

57

22

3

16-Φ21

16-Φ32

Rated output

3.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

±0.1%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input resistance

770Ω ± 10Ω (500kN), 385Ω ± 20Ω (1000kN)

Ultimate overload

300 %F.S

Output resistance

701Ω ± 3Ω (500kN), 350Ω ± 3Ω (1000kN)

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
