Compact structure, high comprehensive accuracy, good long-term stability, can be tensile and compressive two-way loading.
Suitable for hook scale, proportioning weighing control, mechanical and electrical transformation of mechanical scale
2000kg, 3000kg, 5000kg
Inquiry now
|
Capacity |
Size mm |
Weight (kg) | |||
|
kg |
L |
W |
H |
M |
|
|
2000 |
70 |
45 |
86 |
M16×1.5 |
2.2 |
|
3000 |
80 |
50 |
100 |
M18×1.5 |
3.14 |
|
5000 |
92 |
58 |
130 |
M20×2 |
5.5 |
|
Capacity |
2000kg，3000kg，5000kg |
Insulation resistance |
≥5000 MΩ |
|
Rated output |
2.0mv/v±0.1% |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Non-linearity |
0.03%F.S |
Environmental protection |
IP67 |
|
Hysteresis |
0.03%F.S |
Safe overload |
150%F.S |
|
Creep in 30 minutes |
0.03%F.S |
Ultimate overload |
300%F.S |
|
Zero balance |
±1%F.S |
Operating temperature range |
-10℃ ～ +40℃ |
|
Input resistance |
381Ω ±4Ω |
Material |
Alloy steel &Stainless steel |
|
Output resistance |
350Ω ±1Ω |
Cable Length |
5m |
