Apply to crane scale, blending scale, packing scale, electromechanical scale, and special testing device.
50kg, 100kg, 200kg, 500kg, 1000kg, 200kg, 3000kg, 5000kg
Inquiry now
|
Capacity |
Size mm |
|||
|
kg |
A |
H |
B |
M |
|
50,100 |
50.8 |
76.2 |
12 |
M6×1 |
|
200,500,1000 |
50.8 |
76.2 |
19.1 |
M12×1.75 |
|
2000,3000 |
69.8 |
100 |
31.7 |
M24×2 |
|
5000 |
76.2 |
100 |
36.5 |
M24×2 |
|
Capacity |
50kg, 100kg,200kg, 500kg, 1000kg, 2000kg, 3000kg, 5000kg |
Insulation resistance |
≥5000 MΩ |
|
Rated output |
2.0mv/v ± 0.1% |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Non-linearity |
0.03%F.S |
Environmental protection |
IP66 |
|
Hysteresis |
0.03%F.S |
Safe overload |
150%F.S |
|
Creep in 30 minutes |
0.03%F.S |
Ultimate overload |
300%F.S |
|
Zero balance |
±1%F.S |
Operating temperature range |
-10℃ ～ +40℃ |
|
Input resistance |
389Ω ± 3Ω |
Material |
Stainless steel |
|
Output resistance |
350Ω ± 3Ω |
Cable Length |
3m |
