Capacity |
Size mm |
||||
|
t |
L |
L1 |
H |
H1 |
C |
|
10 |
110 |
140 |
145 |
115 |
40 |
|
15 |
130 |
160 |
180 |
110 |
50 |
|
20 |
140 |
170 |
160 |
107.5 |
52.5 |
|
Rated output |
2.0mv/v±0.1% |
Insulation resistance |
≥5000MΩ |
|
Non-linearity |
±0.03%F.S |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Hysteresis |
±0.03%F.S |
Environmental protection |
IP67 |
|
Creep in 30 minutes |
±0.03%F.S |
Safe overload |
150%F.S |
|
Zero balance |
±1%F.S |
Ultimate overload |
300%F.S |
|
Input resistance |
700Ω ± 10Ω |
Operating temperature range |
-10℃ ～ +40℃ |
|
Output resistance |
700Ω ± 2Ω |
Material |
Alloy steel |
