Capacity

Size mm

kg

H

H1

C

C1

M

M1

1…20

11

4

15

20

M3

M3 deep 4

50

11

4

15

20

M3

M3 deep 4

100..2000

15

5

18

25.4

M5

M4 deep 7

5000

25

8

32

40

M12

M4 deep 6

Capacity

1kg, 2kg, 3kg, 4kg, 5kg, 10kg, 20kg(Aluminium alloy)
50kg, 100kg, 150kg, 200kg, 500kg, 1000kg, 2000kg, 5000kg

Insulation resistance

≥5000Ω

Rated output

0.4~0.7mv/v ± 20%（1-20kg）
0.4~1mv/v ± 20% (50-5000kg)

Excitation voltage

4~7V (maximum 8V)  AC/DC

Non-linearity

0.5%F.S

Environmental protection

IP67

Hysteresis

0.5%F.S

Safe overload

150%F.S

Creep in 30 minutes

0.5%F.S

Ultimate overload

300%F.S

Zero balance

±1%F.S

Operating temperature range

-10℃ ～ +40℃

Input resistance

350Ω±3Ω

Material

合金钢或不锈钢

Output resistance

350Ω±2Ω

Cable Length

0.7m
