Capacity

Size mm

t

10t

15t

22t

33t

47t

68t

100t

150t

220t

330t

470t

B2

74

75

75

95

130

130

150

150

225

225

270

B3

30

30

30

40

60

60

70

70

100

100

120

B

75

75

75

95

130

130

150

150

225

225

270

E

7

7

7

7

7

7

7

7

10

10

10

F

6.5

6.5

6.5

10

14

14

16

16

24

24

28

H

50

50

50

65

75

85

90

100

130

145

170

Rated output

2.85mv/v±0.1%

Insulation resistance

≥5000Ω

Non-linearity

0.05%F.S

Excitation voltage

10V (maximum 15V)  AC/DC

Hysteresis

0.05%F.S

Environmental protection

IP68

Creep in 30 minutes

0.03%F.S

Safe overload

150%F.S

Zero balance

±1%F.S

Ultimate overload

200%F.S

Input resistance

4450Ω ± 100Ω

Operating temperature range

-10℃ ～ +40℃

Output resistance

4010Ω ± 2Ω

Material

Alloy steel & Stainless steel
