Rated output

1.0mv/v ±0.1%, 2.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Nonlinearity

±0.1%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep/ 30 minutes

±0.1%F.S/min

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input impedance

350Ω ± 20Ω

Ultimate overload

200 %F.S

Output impedance

350Ω ± 3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
