Capacity (t)

Capacity (kN)

D

D1

D2

D3

H

ΦT

n

0.5

5

mm

90

75

22

12+0.3

25

Φ7

4

1

10

mm

100

80

26

12+0.3

30

Φ11

4

2

20

mm

125

105

42

24+0.3

42

Φ11

8

5 - 10

50 - 100

mm

150

122

48

24+0.3

45

Φ11

8

20 - 30

200 - 300

mm

180

142

70

30+0.3

53

Φ13.5

8

50 - 60

500 - 600

mm

235

190

90

36+0.3

60

Φ17.5

8

100

1000

mm

297

236

105

36+0.3

70

Φ22

8

200

2000

mm

350

300

130

36+0.3

90

Φ25

8

Rated output

2.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

±0.1%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input resistance

770Ω ± 20Ω

Ultimate overload

200 %F.S

Output resistance

700Ω ± 5Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
