IP68 compression load cell, Alloy steel or Stainless steel construction
Fast dynamic response, strong anti-overload capability
Suitable for electronic truck scale, dynamic railroad scale, big capacity, hopper scale, etc.
10t, 20t, 30t, 40t, 50t
Inquiry now
|
Rated output |
2.0mv/v±0.1% |
Insulation resistance |
≥5000Ω |
|
|
Non-linearity |
0.03%F.S |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
|
Hysteresis |
0.03%F.S |
Environmental protection |
IP67 |
|
|
Creep in 30 minutes |
0.03%F.S |
Safe overload |
150%F.S |
|
|
Zero balance |
±1%F.S |
Ultimate overload |
300%F.S |
|
|
Input resistance |
700Ω ± 7Ω |
Operating temperature range |
-10℃ ～ +40℃ |
|
|
Output resistance |
703Ω ± 3Ω |
Material |
Alloy steel |
|
