Fast dynamic response, strong anti-overload capability
Suitable for electronic truck scale, dynamic railroad scale, big capacity, hopper scale, etc.
IP68 compression load cell, Alloy steel or Stainless steel construction
5t, 10t, 20t, 30t, 50t
Inquiry now
|
Rated output |
1.5mv/v±0.1% |
Insulation resistance |
≥5000Ω |
|
Non-linearity |
0.03%F.S |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Hysteresis |
0.03%F.S |
Environmental protection |
IP67 |
|
Creep in 30 minutes |
0.03%F.S |
Safe overload |
150%F.S |
|
Zero balance |
±1%F.S |
Ultimate overload |
300%F.S |
|
Input resistance |
670Ω ± 15Ω |
Operating temperature range |
-10℃ ～ +40℃ |
|
Output resistance |
605Ω ± 5Ω |
Material |
Alloy steel |
