IP68 compression load cell, Alloy steel or Stainless steel construction
Fast dynamic response, strong anti-overload capability
Suitable for electronic truck scale, dynamic railroad scale, big capacity, hopper scale, etc.
250kN，400kN，600kN，900kN
Inquiry now
|
Capacity |
Size (mm) |
||||||||
|
(kN) |
ΦD |
ΦD1 |
ΦD2 |
H |
H1 |
H2 |
H3 |
L |
L1 |
|
250 |
37 |
50 |
72 |
192 |
34 |
51 |
15 |
33 |
62 |
|
400 |
37 |
64 |
85 |
225 |
36 |
57 |
16 |
26 |
69 |
|
600 |
54.4 |
64 |
85 |
225 |
36 |
57 |
16 |
26 |
69 |
|
900 |
54.4 |
64 |
85 |
225 |
36 |
57 |
16 |
26 |
69 |
|
Rated output |
2.0mv/v ± 0.1% |
Insulation resistance |
≥5000Ω |
|
Non-linearity |
±0.03%F.S |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Hysteresis |
±0.03%F.S |
Environmental protection |
IP68 |
|
Creep in 30 minutes |
±0.03%F.S |
Safe overload |
150%F.S |
|
Zero balance |
±1%F.S |
Ultimate overload |
300%F.S |
|
Input resistance |
400Ω ± 15Ω |
Operating temperature range |
-10℃ ～ +40℃ |
|
Output resistance |
351Ω ± 1Ω |
Material |
Aluminum |
