Capacity (t)

Capacity (kN)

D

D1

D2

D3

d

H

H1

T

0.5 - 10

5 - 100

mm

118

100

36

4×5.1

50

43

8-Φ9

20

200

mm

160

135

62

4×5.1

53

45.5

10-Φ14

30

300

mm

172

147

65

4×5.1

74.5

67

12-Φ14

Rated output

2.0mv/v ±0.1%

Insulation resistance

≥5000Ω

Non-linearity

±0.05%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150%F.S

Input resistance

385Ω±20Ω

Ultimate overload

200%F.S

Output resistance

350Ω±3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
