Rated output

3.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

±0.05%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input resistance

770Ω ± 20Ω

Ultimate overload

200 %F.S

Output resistance

702Ω ± 3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
