Rated output

0-10v, 4-20mA

Insulation resistance

≥5000MΩ

Non-linearity

0.1 % F.S

Excitation voltage

10V (maximum 15V)  AC/DC

Hysteresis

0.1% F.S

Environmental protection

IP67

Creep in 30 minutes

0.05 %F.S

Safe overload

150%F.S

Zero balance

±1 %F.S

Ultimate overload

300%F.S

Input resistance

700Ω ±30Ω

Operating temperature range

-10℃～ + 40℃

Output resistance

700Ω ±3Ω

Material

Alloy steel
