Single-Ended Beam
Capacities 250lb~10Klb,
Alloy tool steel construction
Truck/Rail scales
250lb，500lb，1000lb，2000lb，2500lb，3000lb，4000lb，5000lb，10000lb
Inquiry now
|
Capacity |
Size mm |
|||||||||||
|
lb |
H2 |
D |
A |
B |
H |
L |
L4 |
L3 |
L2 |
L1 |
H1 |
M |
|
250, 500 |
12.7 |
13.5 |
13.5 |
30.7 |
23.6 |
130.1 |
25.4 |
76.2 |
12.7 |
72.6 |
1.8 |
1/2-20UNF-2B |
|
500, 1k, 2k, 3k, 4k, 5k |
15.8 |
13.5 |
13.5 |
30.7 |
28.45 |
130.1 |
25.4 |
76.2 |
12.7 |
72.6 |
1.8 |
1/2-20UNF-2B |
|
5k, 10k |
19.1 |
19.8 |
19.8 |
36.6 |
34.04 |
171.5 |
38.1 |
95.3 |
19.1 |
95.3 |
2.5 |
3/4-16UNF-2B |
|
Rated output |
3.0mv/v±0.002 |
Insulation resistance |
≥5000MΩ |
|
Non-linearity |
±0.03%F.S |
Excitation voltage |
10V (maximum 15V) AC/DC |
|
Hysteresis |
±0.03%F.S |
Environmental protection |
IP67 |
|
Creep in 30 minutes |
±0.03%F.S |
Safe overload |
150%F.S |
|
Zero balance |
±1%F.S |
Ultimate overload |
300%F.S |
|
Input resistance |
385Ω ± 5Ω |
Operating temperature range |
-10℃ ～ +40℃ |
|
Output resistance |
350Ω ± 3Ω |
Material |
Alloy steel |
