Capacity

Size mm

Weight

kg

D1

D

(kg)

10-250

8.2

8.2

0.5

300

10.5

11.1

0.5

Size

(mm)

Capacity(kg)

5-200

500

1000

H

89

89

126.5

H1

45

45

60

H3

9

9

14

H4

17

17

22

B

30

30

46

B1

20

20

30

M

M8

M8

M10

Capacity

5kg,10kg,20kg,50kg,100kg,200kg,500kg

Insulation resistance

≥5000 MΩ

Rated output

2.0 mv/v ±0.1%

Excitation voltage

10V (maximum 15V)  AC/DC

Non-linearity

0.03 %F.S

Environmental protection

IP67

Hysteresis

0.03 %F.S

Safe overload

150 %F.S

Creep in 30 minutes

0.03 %F.S

Ultimate overload

300 %F.S

Zero balance

±1 %F.S

Operating temperature range

-10℃ ～+40℃

Input resistance

350Ω ±5Ω

Material

Stainless steel

Output resistance

350Ω ±2Ω

Cable Length

3m
