Rated output

2.0mv/v±0.1%

Insulation resistance

≥5000Ω

Nonlinearity

±0.03%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Hysteresis

±0.03%F.S

Protection class

IP65

Creep/ 30 minutes

±0.02%F.S, ±0.017%F.S

Safe overload

120%F.S

Zero balance

±1%F.S

Ultimate overload

150%F.S

Input impedance

405Ω ± 10Ω

Operating Temp. range

-10℃ ～ +40℃

Output impedance

350Ω ± 3Ω

Cable length

5m
