Capacity (t)

Capacity (Klb)

D

D1

D2

D3

H

H1

H2

H3

SR

n-ΦT

SR1

H4

H5

ΦC

Φ2

0.5 - 7.5

1 - 15

mm

104.7

88.9

31.8

32

53.8

33.8

19

1

15.9

8-Φ7.5

15.9

14

5

41

22.2

10 - 25

25 - 50

mm

120.7

101.6

31.8

38.9

77.8

52.8

24

1

22.2

4-Φ8.7

22.2

19

8

43

38.1

50

100

mm

140

116.8

31.8

50.4

86.2

56.2

29

1

25

8-Φ10.5

25

32

7.8

59

41.3

60 - 100

150 - 200

mm

200

162

50.8

76

125

81.9

42

1.1

45

16-Φ13

45

55

13

98

76.2

Rated output

2.0mv/v ±0.1%

Insulation resistance

≥5000Ω

Non-linearity

±0.05%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.05%F.S

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150%F.S

Input resistance

765Ω±15Ω, 385Ω±15Ω

Ultimate overload

200%F.S

Output resistance

700Ω±5Ω, 350Ω±3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
