Capacity (t)

H

D

D1

H1

SR

15

mm

130

76.1

44

76.1

110

20

mm

150

76.1

44

76.1

130

30

mm

150

76.1

44

76.1

160

40

mm

150

76.1

44

76.1

180

60

mm

210

76.1

44

76.1

220

100

mm

260

95

60

95

290

                           Capacity（t）

A

B

15

mm

160

130

20

mm

180

150

30

mm

200

150

40

mm

200

150

60

mm

260

210

Rated output

2.0mv/v±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

0.03%F.S

Rated excitation

10V (maximum 15V)  AC/DC

Hysteresis

0.03%F.S

Protection class

IP68

Creep/ 30 minutes

0.03%F.S

Safe overload

150%F.S

Zero balance

±1%F.S

Ultimate overload

300%F.S

Input impedance

700Ω ± 20Ω

Operating Temp. range

-10℃ ～ +40℃

Output impedance

706Ω ± 3Ω

Cable length

5m
