Rated output

1.0mv/v±0.1%, 2.0mv/v±0.1%

Insulation resistance

≥5000Ω

Non-linearity

±0.05%F.S

Excitation voltage

5~7V (maximum 8V)  AC/DC

Hysteresis

±0.05%F.S

Environmental protection

IP67

Creep in 30 minutes

±0.05%F.S

Safe overload

150%F.S

Zero balance

±1%F.S

Ultimate overload

300%F.S

Input resistance

380Ω ± 10Ω, 750Ω ± 10Ω

Operating temperature range

-10℃ ～ +40℃

Output resistance

350Ω ± 3Ω, 700Ω ± 5Ω

Material

Alloy steel
