Rated output

1.0mv/v±0.5% (3t),0.7mv/v±0.5% (5t)

Insulation resistance

≥5000MΩ

Nonlinearity

±0.03%F.S

Rated excitation

5~7V (maximum 8V)  AC/DC

Hysteresis

±0.03%F.S

Protection class

IP67

Creep/ 30 minutes

±0.03%F.S

Safe overload

150%F.S

Zero balance

±1%F.S

Ultimate overload

300%F.S

Input impedance

750Ω ±10Ω

Operating Temp. range

-10℃ ～ +40℃

Output impedance

703Ω ±2Ω

Cable length

5m
