Capacity (kN)

D

D1

D2

D3

M

H

H1

H3

H4

h

h1

M1

n-фT

900

mm

279

228.6

122.2

114.3

M72×2-4H

88.9

76.2

76.2

0.8

82.6

69.8

M72×2-4H

16×15.5

1200

mm

279

222.2

122.2

114.3

M72×2-4H

101.6

82

101.6

0.8

95.3

69.8

M72×2-4H

16×20.1

1800

mm

304.8

241.3

144.3

152.4

M90×3-4H

114.3

108

114.3

0.8

95.3

95.3

M90×3-4H

20×20.1

2700

mm

393.7

322.1

196.3

196.9

M120×4-4H

139.7

127

127

0.8

108

108

M120×4-4H

24×23.9

4500

mm

520.7

419.1

267.9

267.9

M150×4-4H

158.8

152.4

177.8

0.8

130

162

M150×4-4H

28×27

9000

mm

660.4

520.7

350.3

355.6

M200×4-5H

196.9

190.5

228.6

2.5

178

184

M200×4-5H

32×33.3

Rated output

4.0mv/v ±0.1%, 2.0mv/v ±0.1%

Insulation resistance

≥5000MΩ

Non-linearity

±0.07%F.S (200klb/900kN),
±0.08%F.S (270klb/1200kN),
±0.12 %F.S (400-600klb/1800-2700kN),
±0.15 %F.S (1000klb/4500kN),
±0.20 %F.S (2000klb/9000kN)

Rated excitation

10V (maximum 15V)  AC/DC

Creep in 30 minutes

±0.07%F.S (200klb/900kN),
±0.08%F.S (270klb/1200kN),
±0.12 %F.S (400-600klb/1800-2700kN),
±0.15 %F.S (1000klb/4500kN),
±0.20 %F.S (2000klb/9000kN)

Protection class

IP67

Zero balance

±1%F.S

Safe overload

150 %F.S

Input resistance

385Ω ±15Ω

Ultimate overload

300 %F.S

Output resistance

350Ω ±3Ω

Operating Temp. range

-10℃ ～ +40℃

Output range

4-20mA, 0-10v, 0-5v, -10v ~ +10v

Cable length

5m
