0.5t, 1t, 2t, 5t, 10t, 15t, 20t, 30t, 50t, 60t, 100t, 150t, 200t
立即询价
|
量程 t |
|
D |
D1 |
D2 |
D3 |
M |
H |
H1 |
H2 |
T1 |
T2 |
N |
|
0.5, 1, 2, 5 |
mm |
105 |
89 |
75 |
32 |
M16 x 1.5 |
37 |
34 |
7.2 |
7.5 |
10.5 |
8 |
|
10, 15, 20 |
mm |
120.6 |
101.6 |
83 |
39 |
M32 x 1.5 |
48 |
41 |
10.5 |
8.5 |
14 |
8 |
|
30, 50 |
mm |
138 |
116.8 |
96.9 |
50.4 |
M40 x 1.5 |
57.2 |
50.8 |
11 |
11 |
18 |
8 |
|
60 |
mm |
153 |
130 |
110 |
70 |
M40 x 1.5 |
58 |
51 |
16 |
10.5 |
17 |
8 |
|
60, 100 |
mm |
198 |
162 |
132 |
76 |
M60 x 2 |
83 |
70 |
18 |
13 |
20 |
16 |
|
150, 200 |
mm |
248 |
210 |
170 |
110 |
M80 x 3 |
100 |
90 |
20 |
17 |
28 |
16 |
|
额定输出 |
2.0mv/v ±0.1% |
绝缘电阻 |
≥5000MΩ |
|
非线性 |
±0.05%F.S |
激励电源 |
10V (maximum 15V) AC/DC |
|
蠕变/30分钟 |
±0.05%F.S |
防护等级 |
IP67 |
|
零点平衡 |
±1%F.S |
安全载荷 |
150 %F.S |
|
输入阻抗 |
385Ω ± 20Ω, 750Ω ± 20Ω |
极限载荷 |
200 %F.S |
|
输出阻抗 |
350Ω ± 3Ω, 700Ω ± 5Ω |
工作温度 |
-10℃ ～ +40℃ |
|
可选输出信号 |
4-20mA, 0-10v, 0-5v, -10v ~ +10v |
导线长度 |
5m |
